Vellamo Relate Waterfall Basin Mixer & Bath Filler Pack

Rated 5.00/5 from 6 customer reviews

Loading delivery estimate...

Klarna
Pay 3 interest-free instalments of £59.99 with Klarna Learn more about Klarna
Clearpay
Pay 4 interest-free instalments of £45.00 with Clearpay Learn more about Clearpay

What's great about it?

  • Curved, angular deck-mounted basin mixer and bath filler set ideal for modern bathrooms
  • Manufactured from reliable solid brass in a Polished Chrome finish that adds sleek appeal
  • Fitted with ceramic disc cartridge valves for longevity and easy operation
  • Supplied with a basin clicker waste at no additional cost for an even more attractive offer

Read full product description

Relate is a bold, angular waterfall tap softened by a curve on the front edge of the tap, and on the underside of the wide flat spout, giving it a beautiful contemporary look that finishes off your bathroom perfectly. Matching bath tap options allow for a co-ordinated look.

Basin Mixer Features:
  • Free slotted clicker waste
  • High quality chrome-plated brass tap
  • Suitable for all water systems from 0.2 bar pressure
  • Works on low pressure as well as high pressure systems
  • Ceramic disc technology
  • 10 year guarantee

Basin mixer flow rates:
  • At 0.2 bar - 5.0 l/min
  • At 0.5 bar - 8.1 l/min
  • At 1.0 bar - 11.6 l/min
  • At 1.5 bar - 14.4 l/min
  • At 2.0 bar - 16.7 l/min
  • At 3.0 bar - 20.3 l/min

Bath Filler Features:
  • High quality design and build
  • Material - Brass body
  • Colour/Finish - Polished Chrome
  • Easy installation
  • Deck Mounted
  • Minimum water pressure required - 0.2 Bar
  • Cartridge - 3/4" ceramic disc valve
  • 10 year guarantee

Bath filler flow rates:
  • At 0.2 bar - 12.6 l/min
  • At 0.5 bar - 21.5 l/min
  • At 1.0 bar - 30.5 l/min
  • At 1.5 bar - 37.1 l/min
  • At 2.0 bar - 40.9 l/min
  • At 3.0 bar - 40.9 l/min

Downloads
Cleaning Instructions
Product Overview
Product Code vellamo-relte-wf-basin-bath-pk
Type Basin & Bath Tap Packages
Brand Vellamo
Brand Range Vellamo Relate
GuaranteeMore information 10 Years

Guarantee

Please note that these guarantees are provided by the manufacturer, and will be subject to individual exclusions, exceptions, and terms and conditions, for example avoiding abrasive bleach-based cleaning products.

If you need further info about a specific manufacturer's guarantee, please contact our team.


Features
Temperature Control Manual
Cartridge TypeMore information Ceramic Disc
Taps use either a ceramic disc cartridge or a rubber compression washer to control flow. Rubber washers will naturally wear down with use, and the tap handle will require more and more rotations to turn on or off. On the plus side, it's very easy to replace a rubber washer and they're available everywhere.

Ceramic disc cartridges need only a 90-degree rotation to fully open or close, and the 2 ceramic plates are incredibly hard-wearing and resilient. They're more expensive to make, but they allow for a huge range of designs, easy operation and simple maintenance if needed.

Whilst it is rare for a ceramic cartridge to need replacing, you may very occasionally need to remove and rinse the cartridge if grit or debris within the water system is preventing the 2 plates from closing properly. Much like replacing a rubber washer, this is a quick and easy job, and will ensure many years of use.
Style
Mounting Type Deck Mounted
Finish Polished Chrome
Shape Square
Handle Type Lever
Spout Type Straight Spout, Waterfall Spout
Texture Polished
Style Modern
Flow Rate
Minimum Water PressureMore information 0.2

Minimum Water Pressure

Your water pressure depends on your home's water system. It’s important to consider water pressure when buying a new tap or shower. Buying a product with a minimum water pressure that’s too high for your home will result in poor performance.

- With a combi boiler you can usually expect between 1 and 2 bar

- With a gravity system (cold water tank in attic) you may have as little as 0.1 or 0.2 bar upstairs, and perhaps 0.5 bar downstairs

- With a high pressure unvented system (hot water cylinder, no cold water tank) you will generally have between 1 and 3 bar

You can install an item with a low minimum pressure rating on a high pressure system, but avoid installing an item with a high minimum rating on a low pressure system! Read our guide to water pressure to learn more.
