We've hand-picked these items because they are a great choice alongside the Flova Smart Concealed Manual Mixer Valve with 3-Way Diverter
The Flova Smart's deceptively simple lines offer a modern and minimal look softened by subtle curves to ensure the best possible experience. Manufactured from virgin brass, the Smart Range is built with contaminant-free material with incontestable durability. In addition, the brassware is manufactured with Diamond Chrome finish, for a smooth and dust-proof polished surface with a long-lasting shine. As proof of its quality, all Flova brassware is supplied with a 10-year warranty; and all working parts, such as cartridges and seals, are covered for 3 years.
Features:
Features:
- European CE certificated
- Diamond Chrome plating for ease-of-clean & high-shine finish
- Constructed from low-lead high-quality brass
- Rust & corrosion resistant
- Quarter turn ceramic disc technology for smooth & drip-free performance
- Single lever for simple operation of flow & temperature
- Non-thermostatic manual temperature setting
- Integrated triple diverter for pairing with 3 outlets
- Wall-mounted installation with concealed fixings
- Standard 1/2" inlet/outlet size
- Minimum 0.5 bar water pressure is recommended
- A pressure reducing valve is recommended when water supply exceeds 3.0 bar
- Fully compatible with UK plumbing systems
- 10 year brassware guarantee
- 3 year guarantee on all working parts
| Product Code | SMSHVO3WD |
|---|---|
| Type | Concealed Shower Valves |
| Brand | Flova |
| Brand Range | Flova Smart |
| GuaranteeMore information | 15 Years |
Guarantee
Please note that these guarantees are provided by the manufacturer, and will be subject to individual exclusions, exceptions, and terms and conditions, for example avoiding abrasive bleach-based cleaning products.
If you need further info about a specific manufacturer's guarantee, please contact our team.
| Number of Outlets | 3 Outlets |
|---|---|
| Temperature Control | Manual |
| Cartridge TypeMore information | Ceramic Disc |
Taps use either a ceramic disc cartridge or a rubber compression washer to control flow. Rubber washers will naturally wear down with use, and the tap handle will require more and more rotations to turn on or off. On the plus side, it's very easy to replace a rubber washer and they're available everywhere.
Ceramic disc cartridges need only a 90-degree rotation to fully open or close, and the 2 ceramic plates are incredibly hard-wearing and resilient. They're more expensive to make, but they allow for a huge range of designs, easy operation and simple maintenance if needed.
Whilst it is rare for a ceramic cartridge to need replacing, you may very occasionally need to remove and rinse the cartridge if grit or debris within the water system is preventing the 2 plates from closing properly. Much like replacing a rubber washer, this is a quick and easy job, and will ensure many years of use.
Ceramic disc cartridges need only a 90-degree rotation to fully open or close, and the 2 ceramic plates are incredibly hard-wearing and resilient. They're more expensive to make, but they allow for a huge range of designs, easy operation and simple maintenance if needed.
Whilst it is rare for a ceramic cartridge to need replacing, you may very occasionally need to remove and rinse the cartridge if grit or debris within the water system is preventing the 2 plates from closing properly. Much like replacing a rubber washer, this is a quick and easy job, and will ensure many years of use.
| Mounting Type | Wall Mounted |
|---|---|
| Finish | Polished Chrome |
| Shape | Oval |
| Handle Type | Lever, Single Control |
| Texture | Polished |
| Style | Modern |
| Orientation | Portrait |
| Width (mm) | 120 |
|---|---|
| Height (mm) | 185 |
| Minimum Water PressureMore information | 0.5 |
|---|
Minimum Water Pressure
Your water pressure depends on your home's water system. It’s important to consider water pressure when buying a new tap or shower. Buying a product with a minimum water pressure that’s too high for your home will result in poor performance.
- With a combi boiler you can usually expect between 1 and 2 bar
- With a gravity system (cold water tank in attic) you may have as little as 0.1 or 0.2 bar upstairs, and perhaps 0.5 bar downstairs
- With a high pressure unvented system (hot water cylinder, no cold water tank) you will generally have between 1 and 3 bar
You can install an item with a low minimum pressure rating on a high pressure system, but avoid installing an item with a high minimum rating on a low pressure system! Read our guide to water pressure to learn more.
